KD-350
Automatic pillow packaging machine
  • description>
  • performance>
  • parameter>
  • Online inquiry>
product description


Product advantages

It adopts original single servo or double servo motor control, which is more intelligent than other similar inverter motors or inverter controlled products at home and abroad, with higher packaging precision, wider adjustable range, more precise control and lower scrap rate. Better stability. Thanks to the world's leading fully open box structure, the transmission structure is clear at a glance, and maintenance is more convenient;



Technical performance

1、

Compact structure, stable performance and easy operation.

2、

Double frequency conversion control, the bag length can be set and cut, no need to adjust the empty walk, one step in place, saving time and film.

3、

Adopt imported electrical appliances, touch human-machine interface, parameter setting is convenient and quick, fault self-diagnosis function, fault display is clear at a glance.

4、

The high-sensitivity photoelectric eye color tracking makes the sealing and cutting position more accurate.

5、

Temperature independent PID control, better suited to various material envelopes.

6、

Positioning stop function, no sticking knife, no film.

7、

The rotating system is simple, the work is more reliable, and the maintenance is more convenient.

8、

All control is implemented by software, which is convenient for function adjustment and technical upgrade, and never lags behind.

9、

Suitable for bread, moon cake, biscuit food packaging.

parameter
Bag size (mm)

length 65*330mm width 30*150mm height 5*60mm

Longitudinal and transverse seal strength (Newton/mm)

15N/mm²

Packing speed (bag / minute)

40~250Bags/min

Packaging film width (mm)

90~350mm

Power specification

220V 50/60Hz 2.2KW

Machine weight (kg)

680KG

Dimensions (length x width x height)

4000x1100x1560mm
