Product description

This machine is made by extrusion molding and then automatically packaged and printed. The whole process is automated. The packaging speed is fast and cloud-like. It is suitable for all kinds of rubber clay plasticine clay clay type. The cutting and packaging is the first to adopt the new servo cutting system packaging. Fast speed tracking accurately solves the problem of domestic plasticine packaging waste packaging and packaging. It is difficult to operate at a slow speed. This machine is easy to operate and easy to use (can also be customized for various monochrome or multi-color plasticine molding packaging lines). The range is 1.2~3cm (more than can be done, but the equipment such as motor and screw should be increased). It is convenient and simple, and the length of the extruded mud can be controlled in the program. Can be tracked online with the packaging machine.

Extrusion system

Mainly composed of screw and barrel, it is a key part of the extruder, and the color mud passes through the extrusion system a squeezed and uniform fluid, and under the pressure established by this process, is continuously and quantitatively pressed by the screw to press the head.

Styling device

The first in China to adopt the servo slitting technology. Its function is to stabilize the color mud extruded from the machine head according to the predetermined shape and to finish it, so as to obtain a more accurate cross-sectional shape, size and bright surface.

Color mud extruder control part

Adopting our advanced programmable controller, its powerful control function and flexible modular structure can meet the control of various types of extrusion equipment. It can be combined with our packaging machine to form a color mud production line; human-machine interface, large-screen color display It can conveniently monitor and operate the neat equipment; the speed control part color frequency conversion speed control device can ensure the smoothness and synchronization of all parts of the extrusion equipment by using superior vector control performance.

In order to prevent the barrel from being heated by the extrusion friction, the temperature is too high to make the color mud heat, and the cooling device is used to cool the water tank and spray to cool.

First, the cooling device adopts the inner diameter sizing method

Features; high precision of inner diameter and good internal surface quality, which is conducive to the flow of materials and makes the outer surface more beautiful.

Second, the fault alarm function can display the cause of the fault, the fault location

Third, color mud extruder, color horizontal single screw type, with the following characteristics

1) The heat generated by friction is small

2) The shear force received by the special material is relatively uniform

3) Large output capacity and stable extrusion

4) The barrel cleaning is convenient
